JMX-P Series

Classification:

Small And Medium-Sized Packaged And Unpackaged Product Testing

immediate consultation
  • Detail

    Product Overview

    Junmao JMX-P series intelligent X-ray foreign body detector is widely used for foreign body and defect detection in product packaging, helping companies control product quality, improve safety, avoid consumer complaints and product recalls, and achieve high cost-effectiveness.



    Product Features

    01

    Using advanced beryllium window radiation source, clear imaging and high detection accuracy

    02

    Equipped with various rejection devices such as flip plate type, push plate type, and air blowing type to meet the needs of different usage scenarios

    03

    Intelligent fault diagnosis and accurate alarm facilitate timely troubleshooting and
    improve maintenance efficiency

    04

    Anti-slip crawler drive structure, no manual adjustment required, smoother material transmission and more stable operation

    05

    Provide solutions for products in various forms such as bags/boxes/cases, bottles, cans, bulk, and no packaging

    06

    The design is hygienic and has no dead corners to prevent moisture accumulation. It can quickly drain moisture by itself to avoid providing a growth environment for microorganisms

    Application Areas

    ● Dairy products ● Snack foods ● Meat products ● Baked goods ● Frozen foods ● Fruit and vegetable products ● Pre-prepared meals ● Pharmaceuticals



    Application Examples

    Product Parameters

    Product Model

    JMX-P4020

    JMX-P6030

    X-ray Output

    80kV/8.0mA adjustable (maximum 350W)

    100kV/8.0mA adjustable (maximum 350W)

    Sensor Type

    0.4 regular/0.4TDI/0.1TDI

    0.4 regular/0.4TDI/0.1TDI

    No-load sensitivity(mm)

    Stainless steel ball ≥φ0.3, stainless steel wire ≥φ0.2*2, glass ball ≥p1.0, ceramic ball ≥φ1.0

    Stainless steel ball ≥φ03, stainless steel wire ≥φ02*2, glass ball ≥φ10, ceramic ball ≥φ1.0

    Detection size (mm)

    Width ≤ 400mm, height ≤ 200mm

    Width ≤ 600mm, height ≤ 300mm

    Conveyor belt width (mm)

    450mm

    660mm

    Conveyor belt speed (m/min)

    10-90m/min

    10-60m/min

    Rejection device

    Flip plate/push plate/swing arm/air blowing etc. optional

    Flip plate/push plate/air blowing etc. optional

    Loading capacity(kg)

    10kg

    50kg

    power supply

    Single phase AC220±10%V,50/60Hz,2kVA

    Single-phase AC220±10%V,50/60Hz,2.5kVA

    Gas source requirements

    0.6-0.8 MPa

    0.6-0.8 MPa

    Protection level

    IP66 in the product channel, IP65 in other areas

    IP66 in the product channel, IP65 in other areas

    Usage Environment

    Ambient temperature -10~40℃; relative humidity 30-90%, no condensation

    Ambient temperature -10~40℃; relative humidity 30-90%, no condensation

    Net weight(kg)

    450kg

    600kg

    Main material

    SUS304

    SUS304

    Radiation safety

    <1uSv/h

    <1uSv/h

    Conveyor belt material

    Food grade PU

    Food grade PU
